Model: HYD-CRL-40

HYD-CRL-40

Hydraulic Compact Roll Lifter 400 lb. Capacity Blue

A compact roll lifter provides an efficient approach to loading and unloading large, heavy rolls. Simply designed, the cradle is lifted and lowered by use of the hydraulic foot pedal. For safe loading and unloading of rolls, ramps are attached to the front of the cradle to assist the user. The ramps can be placed upright to lock the product into position or can be unfolded to allow the release of the product. The narrow wheel base allows the lifter to be used in compact and crowded areas. Constructed of steel with a blue powder coat finish.

  • Manually lifted and lowered for precise load heights
  • Folding foot pedal for compact storage
  • Horizontal handrail provides steady user maneuvering
  • Poly on steel swivel casters
Ship Weight (lbs.): 205 Size: 24"W x 36"L x 68"H Color: Blue 48 Hr. QuickShip

Uniform Capacity (lbs.): 400 Operation Type: Hydraulic Foot Pump Handle Type: Push
Swivel Caster QTY: 2 Swivel Caster Size (in.): 6x2 Rigid Caster Qty: 2
Rigid Caster Size (in.): 2x1.5 Caster Material: Poly on Steel Caster Color: Red

Marketing Specs.

MFG Model # (Series)
HYD-CRL-40
Product Name
Hydraulic Compact Roll Lifter 400 lb. Capacity Blue
UPC
691215373173
GTIN
00691215373173
Taxonomy 1
Material Handling
Taxonomy 2
Lifting Equipment
Taxonomy 3
Roll Lifters
Assembled Depth (in.)
36
Assembled Width(in.)
24
Assembled Height(in.)
68
Assembled Weight(lbs.)
180
Color/Finish
Blue
Material
Steel
Option? Y/N
N
Sell UOM
EA-Each
Country Of Origin
China
Approval Drawing Required? Y/N
N
Assembly
Assembled

Logistics

Packaging Level
BASE_UNIT_OR_EACH
Package Depth (in.)
48
Package Width (in.)
40
Package Height (in.)
73
Package Weight (in.)
205
Subclass
6
Freight Class
300
NMFC Code
Conveyors Elevators or Lifts NOI
NMFC Number
120080
LTL Freight
LTL Palletized
UNSPSC
24100000
HTSUS Number
8427900090
USMCA HS
8427.90
Origin Criterion
NO
Certification Indicator
NO
ECCN
EAR99
US Shipping Point
Angola, IN
Supplier Postal Code
46703
Hazardous Material? Yes/No
No
MSDS? Yes/No
No
Batteries Included?
No

Warranty

Warranty
Yes
Manufactuer Warranty
Warranty Type
Limited - Parts
Cancelable? Y/N
Y
Returnable? Y/N
Y
California Prop 65 Compliant?
Unknown

Quickship Item?


48-Hour Quickship Item

Can It Ship UPS/FedEx?


LTL - Must Go Truck

Image Gallery


PDF Documents


Details For Model: HYD-CRL-40


HYD-CRL-40

Hydraulic Compact Roll Lifter 400 lb. Capacity Blue

A compact roll lifter provides an efficient approach to loading and unloading large, heavy rolls. Simply designed, the cradle is lifted and lowered by use of the hydraulic foot pedal. For safe loading and unloading of rolls, ramps are attached to the front of the cradle to assist the user. The ramps can be placed upright to lock the product into position or can be unfolded to allow the release of the product. The narrow wheel base allows the lifter to be used in compact and crowded areas. Constructed of steel with a blue powder coat finish.

  • Manually lifted and lowered for precise load heights
  • Folding foot pedal for compact storage
  • Horizontal handrail provides steady user maneuvering
  • Poly on steel swivel casters
Dimensions: 24"W x 36"L x 68"H Sell UOM: EA-Each Color: Blue
Material: Steel UPC: 691215373173 GTIN: 00691215373173
Warranty: -- Shipping Weight: 205 Quickship Item? --
Can It Ship UPS? -- Option? N Origin: China
Assembly: Assembled Packaging: BASE_UNIT_OR_EACH Drawing Required? N
Uniform Capacity (lbs.): 400 Operation Type: Hydraulic Foot Pump Handle Type: Push
Swivel Caster QTY: 2 Swivel Caster Size (in.): 6x2 Rigid Caster Qty: 2
Rigid Caster Size (in.): 2x1.5 Caster Material: Poly on Steel Caster Color: Red
