PEL-RR

Printer Friendly
Available
PEL-RR
PEL-RR PEL-RR PEL-RR PEL-RR PEL-RR

Steel Quick Lift Reel Rotator Attachment For PEL 100 Lb. Capacity Models

The reel rotator attachment is designed for rotating and maneuvering reels. The manual rotator lets the user work at the speed that best fits the conditions. A simple installation allows the user to obtain immediate use and diminish the amount of bending and lifting of heavy objects. A yellow finish promotes visibility and safety while transferring units.

  • Simply attachable
  • Allows product to be rotated
  • Pre-drilled attachment holes
  • Promotes ergonomic lifting
Assembled Wt.(lbs.): 40 Assembled Size: 8.375"W x 17.9375"L x 20.625"H

Total Ship Wt.(lbs.): 40 (only 1 package) Package 1 Size: 9"W x 18"D x 21"H Color: Yellow / Silver

Arbor (in.): 2-15/16 Arbor Length (in.): 10-11/16 Usable Arbor Length (in.): 9
Suitable for Core Diameter size (in.): 3 Maximum Uniform Capacity (lbs.): 100 Overall Length (in.): 17-15/16
Overall Width (in.): 8-3/8 Overall Height (in.): 23-5/8

Quickship Item?


NOT A Quickship Item

Can It Ship UPS/FedEx?

Parcel - Can Go UPS

Image Gallery

PDF Documents

90 Days Limited Warranty

Details For Model: PEL-RR
Available
PEL-RR

Steel Quick Lift Reel Rotator Attachment For PEL 100 Lb. Capacity Models

The reel rotator attachment is designed for rotating and maneuvering reels. The manual rotator lets the user work at the speed that best fits the conditions. A simple installation allows the user to obtain immediate use and diminish the amount of bending and lifting of heavy objects. A yellow finish promotes visibility and safety while transferring units.

  • Simply attachable
  • Allows product to be rotated
  • Pre-drilled attachment holes
  • Promotes ergonomic lifting
Dimensions: 8.375"W x 17.9375"L x 20.625"H Sell UOM: -- Color: Yellow / Silver
Material: -- UPC: -- GTIN: --
Warranty: -- Shipping Weight: 40 Quickship Item? --
Can It Ship UPS? -- Option? -- Origin: --
Assembly: -- Packaging: -- Drawing Required? --
Arbor (in.): 2-15/16 Arbor Length (in.): 10-11/16 Usable Arbor Length (in.): 9
Suitable for Core Diameter size (in.): 3 Maximum Uniform Capacity (lbs.): 100 Overall Length (in.): 17-15/16
Overall Width (in.): 8-3/8 Overall Height (in.): 23-5/8
