SWR-CPL-SM

Printer Friendly
Available
SWR-CPL-SM
SWR-CPL-SM

Factory Installed Pickup Loop 25 In. x 54-5/8 In. Connects Steel Wheel Riser Units

This central pick-up loop connects two (2) wheel risers allowing a fork truck to easily position and move risers as one.

  • Factory installed
  • Raised diamond tread plate surface provides a non-slip grip
  • Brown liquid paint finish
  • Built in compliance with OSHA/ANSI B56.1 part 3 sec 38
Assembled Wt.(lbs.): 54 Assembled Size: 54.625"W x 25"L x 5.4375"H

Total Ship Wt.(lbs.): 55 (only 1 package) Package 1 Size: 102"W x 8"D x 3"H Color: Brown Non-Returnable

Overall Width (in.): 54-5/8 Width Between Risers When Installed (in.): 53-1/8 Overall Height (in.): 5-7/16
Height from Ground to Top of Side Loops When Installed (in.): 5-11/16 Overall Depth (in.): 25 Fork Pocket Width (in.): 7-1/2
Fork Pocket Height (in.): 2-1/2

Quickship Item?


NOT A Quickship Item

Can It Ship UPS/FedEx?


LTL - Must Go Truck

Image Gallery

PDF Documents

30 Days Limited Warranty

Details For Model: SWR-CPL-SM
Available
SWR-CPL-SM

Factory Installed Pickup Loop 25 In. x 54-5/8 In. Connects Steel Wheel Riser Units

This central pick-up loop connects two (2) wheel risers allowing a fork truck to easily position and move risers as one.

  • Factory installed
  • Raised diamond tread plate surface provides a non-slip grip
  • Brown liquid paint finish
  • Built in compliance with OSHA/ANSI B56.1 part 3 sec 38
Dimensions: 54.625"W x 25"L x 5.4375"H Sell UOM: -- Color: Brown
Material: -- UPC: -- GTIN: --
Warranty: -- Shipping Weight: 55 Quickship Item? --
Can It Ship UPS? -- Option? -- Origin: --
Assembly: -- Packaging: -- Drawing Required? --
Overall Width (in.): 54-5/8 Width Between Risers When Installed (in.): 53-1/8 Overall Height (in.): 5-7/16
Height from Ground to Top of Side Loops When Installed (in.): 5-11/16 Overall Depth (in.): 25 Fork Pocket Width (in.): 7-1/2
Fork Pocket Height (in.): 2-1/2
